Mirror Light

LEDLinear-Java L580 10W-830/840-WH

Product Code
521028003000
  • Decorative wall luminaire with delicate design
  • IP44 waterproof, suitable for bathrooms and comparable spaces
  • Excellent lighting uniformity
  • Integrated CCT switch for color selection (3000K-4000K)

Specifications

Electrical data

Nominal voltage 220|240 V
Max. system power 10 W
Voltage type AC
Power factor 0.9
Max. number of luminaires per miniature circuit breaker B16 (MCB) 95
Max. number of luminaires per miniature circuit breaker C16 (MCB) 95
Max. inrush current 9.1 A
Inrush time 31.8
Displacement factor (DF) ≥ 0.9
Max. number of luminaires per miniature circuit breaker C10 (MCB) 59
Max. number of luminaires per miniature circuit breaker C13 (MCB) 77
Frequency 50|60 Hz

Photometrical data

Colour temperature 3000|4000 K
Rated luminous flux according to IEC 62722-2-1 1200 lm
Luminaire efficacy 130 lm/W
Equivalent to TL 1x18W
Colour consistency (SDCM) 4
Colour rendering index (CRI) > 80
CIE Flux Code 49 80 96 100 100

Light technical data

Beam angle 110°

Lifespan

Lifetime (L70) 50000 h
On-/Off-cycles 100000

Capabilities

Dimmability On-Off
With sensor No
Sensor technology No sensor
Sensor type No sensor

Certificates and standards

Protection class I
Degree of protection (IP) IP44
Impact strength IK02
Glow wire test 750°C
Risk group (EN 62471) RG0
Type of control gear LED operating device current-controlled
With control gear Yes
Driver failure rate (at 5,000 hrs) 1%
Input current 0.06 A
Wirethrough No
Housing colour White
Optical material Polycarbonate
Cover material Polycarbonate
Finishing White RAL9003
Length 580 mm
Width 72 mm
Height/depth 66 mm
Application temperature 25°C
Storage environment -25|50°C
Operating temperature -10|45°C
EAN codeEU HS CodePackagingAmountSize (L x W x H)Weight
694149177513594051190CT10.84 x 0.13 x 0.125 m1.096 KG
